Ll303 Concox

LL303 The LL303 is a 4G LTE solar energy tracker designed for the management of construction vehicles and boats. With the solar panel, magnetic charger, and IP67 waterproof rating, this device is ideal for a variety of implementations that require long standby time and continuous optimal performance. LTE communication with GSM (2G) backup ensures a solid connection in almost all cases. In addition to these features, the multiple working modes, various peripheral accessories, and set of event-triggered alerts make the LL303 a device to consider in a fleet management strategy.

Specifications

Manufacturer Model Type I/O Battery Communication Methods
Concox LL303 GPS Yes - Internal Battery LTE/GSM/GPRS

Features

GNSS
Positioning System GPS+BDS+LBS+Wi-Fi+AGPS
Positioning Accuracy <2.5m PEC
Tracking Sensitivity -165dBm
Acquisition Sensitivity -148dBm
TTFF (Open Sky) Average Hot Start ≤1 sec
Average Cold Start ≤32 sec



Cellular

Communication Network LTE Cat 1/Cat M1/Cat NB2/GSM
Frequency

LL303-C:

LTE-FDD: B1/B3/B5/B8

LTE-TDD: B34/B38/B39/B40/B41

LL303-E:

LTE-FDD: B1/B3/B5/B7/B8/B20/B28

LTE-TDD: B38/B40/B41

G/M: B2/B3/B5/B8

LL303-L:

LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28

LTE-TDD: B40

G/M: B2/B3/B5/B8

LL303-A:

LTE-FDD: B2/B4/B5/B12/B13/B25/B26/B66

G/M: B2/B3/B5/B8



Power

Battery 10,000mAh/3.7V Industrial Grade Lithium Polymer Battery
Solar Power 5V/390mA (Standard Operating Voltage/Current @STC) STC: Direct Illumination with 38,000lux Halogen Lamp on Test Bench.
Magnetic Charger 5V/2A
Working Modes Mode 1: Normal GPS Mode Mode 2: Tracking Mode Mode 3: Power Saving Mode
Standby Time Up to 2 years in Power Saving Mode



Interface

LED Indication Cellular (Green), Power (Red)
SIM Card Nano SIM
Tamper-proof Hall Effect Sensor



Physical Specification

Dimensions 200.0 x 90.0 x 25 mm (without base)
Weight 480g (without base)



Operating Environment

Operating Temperature –20 u2103 to +70 u2103
Operating Humidity 5%uff5e95%, non-condensing
IP Rating IP67



Feature

Sensors Accelerometer, Temperature and Humidity Sensor, Hall Effect Sensor
Bluetooth Supports BLE 5.0 protocol
Scenarios Low Battery Alert, Tamper Alert, Vibration Alert
